Product Characteristics

1.     Strong compactor capacity

When the dynamic compactor is not equipped with an additional device, the maximum weight of the compactor can reach 55t, and the compactor energy level can reach 11000KN. m. When equipped with a gantry, the maximum weight of the compactor can reach 112t, and the compactor energy level can reach 28000KN. m, which can meet the requirements of most dynamic compactor construction.

2.     High construction efficiency

Adopting an integrated design of mechanical and hydraulic systems, which combines mechanical and hydraulic components. This equipment adopts a dual speed reducer, which can choose the rope speed and tension according to the working conditions. The speed is convenient and fast, and the lifting force is large, the lifting speed is fast, the lifting ability is stable and reliable, and the construction efficiency is high.

3.     Safe, reliable and durable

The base of the car is equipped with hydraulic control legs, and the base is connected to the track frame by a power pin. It is controlled by a six way control valve to ensure the convenience of disassembly and assembly of the entire machine and facilitate transportation during transfer; The main winch adopts a mechanical internal expansion belt for lifting, with a maximum single rope tension of 30t. And it is equipped with an air storage tank to reserve air pressure and prevent the equipment from losing or swinging hammers after the engine is turned off, which better protects the vehicle body. Equipped with large caliper disc brakes and pneumatic hydraulic braking systems, the overall safety factor of the machine is improved.

4.     Convenient transportation

The transportation size of the host is 8670X3500X3200mm, with a maximum individual weight of<49t, a counterweight of approximately 43t, and a total weight of approximately 142t. During transportation, only the tracks, arms, and counterweights need to be removed. The main engine is equipped with leg oil cylinders, which do not require disassembly for transportation. The rear counterweight can be separated from the rear engine shed, making transportation convenient and cost-effective.

Dynamic Compactor BW11000 Technical Parameter
